M07u Mechanical Seal Multiple Spring M01u M02u M03u M04u M05u M06u M09 Component Seals
- Product No.：M07U/M01U/M02U/M03U/M04U/M05U/M06U/M09
M07U Mechanical Seal Multiple Spring M01U M02U M03U M04U M05U M06U M09 Component Seals
The AES M07U is a seal, which can be categorized as a multi spring seal. It is an alternative to the Qseals QFMS33, Roten S and Vulcan Type 50. It is suited for the Inoxpa M25 Blender, Inoxpa Prolac R-15A, Inoxpa Prolac R-20B and 48 others.
The AES M07U is a seal, which can be categorized as a multi spring seal. It is an alternative to the Qseals QFMS33, Roten S and Vulcan Type 50. It is suited for the Inoxpa M25 Blender, Inoxpa Prolac R-15A, Inoxpa Prolac R-20B and 48 others.
Primary Rotary Face
Stainless Steel
Tungsten Carbide
Sintered SiC
Primary Stationary Face
Carbon
Tungsten Carbide
Sintered SiC
Primary Elastomer
FKM
Metric Sizes Table
| Size | d1 | d3 | d7 | I1 | I4 |
|---|---|---|---|---|---|
| 158 | 15.8 | 44.5 | 36.1 | 10.5 | 24 |
| 254 | 25.4 | 53.5 | 44 | 10 | 24 |
| 381 | 38.1 | 74 | 64 | 15.5 | 28 |
Imperial Sizes Table
| Size | d1 | d3 | d7 | I1 | I4 |
|---|---|---|---|---|---|
| 158 | 0.625 | 1.752 | 1.421 | 0.413 | 0.945 |
| 254 | 1 | 2.106 | 1.732 | 0.394 | 0.945 |
| 381 | 1.5 | 2.913 | 2.52 | 0.61 | 1.102 |
